BUILD LAB / PROJECT 001
G30.REDEFINED.
NINEBOT MAX / THE 30S BUILD
A familiar silhouette. A completely different machine. Two battery packs, dual Seven 18 VESCs and a pair of Lonnyo 65H motors turn this G30 into a Modlabs build.
001 / BUILT BY MODLABS
- TOP SPEED / GPS
- 139KM/H
- PEAK POWER
- 38KW
- BATTERY SYSTEM
- 30S6P
- LONNYO / 22×3 WINDING
- 2×65H
Speed and power figures as reported by Modlabs.
Seven 18 (30S)
Rear controller
- PHASE
- 300A
- BATTERY
- 200A
- FWK
- 35A
Configured current limits.
FWK = field weakening.
Tenpower 50XG
Middle of the deck
- CONFIGURATION
- 20S6P
- CELLS
- 120× 50XG
- BMS
- ANT 220–550A
Paired with the external 10S6P pack
for the complete 30S6P system.
Seven 18 (30S)
Front controller
- PHASE
- 250A
- BATTERY
- 180A
- FWK
- 45A
Configured current limits.
FWK = field weakening.
Hover a part, tap a marker, or choose a component above.
01 / POWER SYSTEM
TWO PACKS.
ONE 30S BUILD.
Hover the highlighted parts to inspect the controllers and the internal battery. A 20S6P pack inside the deck pairs with a 10S6P external pack, both using Tenpower 50XG cells, to form the 30S6P system.
HOVER A COMPONENT / TAP A MARKER ON MOBILE
TENPOWER 50XG
ANT 220–550A BMS
Housed inside the G30 deck.TENPOWER 50XG
ANT 220–550A BMS
Mounted in the external battery bag.30S6P COMBINED180 CELLS / TWO BMS UNITS
02 / HARDWARE
THE BUILD SHEET.
The complete setup, from the cells inside the deck to the hardware at both wheels.
| SYSTEM | HARDWARE | CONFIGURATION |
|---|---|---|
| 01PLATFORM | Ninebot MAX G30 | Custom 30S dual-motor build |
| 02BATTERY | 20S6P + 10S6P Tenpower 50XG | 30S6P combined / 180 cells |
| 03BMS | 2× ANT 220–550A BMS | One BMS per battery pack |
| 04CONTROLLERS | 2× Seven 18 30S VESC | Separate front and rear controllers |
| 05MOTORS | 2× Lonnyo 65H | 22×3 winding / front and rear |
| 06TIRES | 2× PMT tires | Front and rear |
| 07BRAKES | 2× Magura MT5 | Hydraulic disc brakes / front and rear |
CONTROLLER CONFIGURATION // SEVEN 18 (30S)
Rear controller
SEVEN 18 / 30S
- Phase current
- 300A
- Battery current
- 200A
- Field weakening
- 35A
Front controller
SEVEN 18 / 30S
- Phase current
- 250A
- Battery current
- 180A
- Field weakening
- 45A
Configured build settings, as supplied by Modlabs.
03 / BUILD MEDIA
LOOK CLOSER.
Original clips of the complete build and the details that make it yours. Press play to explore.
The full walkaround
From the complete silhouette to the cockpit.
The front end
Front drive, brake and external battery bag.
The rear drive
A close look at the rear motor and brake.
After dark
The complete build, with the details lit up.
